Ewoc

Ewoc 20'' 6S

Unavailable

  • Suntour XCT 80mm Fork
  • Kenda Amrak 20x2.2 Tires
  • Shimano TZ-500 Rear derailleur
Compare + Added! Delete

Select your specs

Technical
Specifications

Ewoc 20'' 6S

Compare + Added! Delete

Manufacturing

Designed in Canada

Download the manual

Frame

  • FRAME Aluminum Optimum G02
  • FORK SR Suntour XCT-DS Jr | 63mm
  • HEADSET CH-9280 | Zero Stack
  • SEAT CLAMP Alloy | Quick Release | 31.8mm

Cockpit

  • HANDLEBAR Devinci | B:25.4 mm | R:20mm | W:600mm
  • STEM Devinci | B:25.4mm | 10°
  • SADDLE Devinci
  • SEATPOST Devinci | 27.2mm
  • GRIPS Kraton

Brakes

  • REAR BRAKE CALIPER Tektro Aries MD-M280 | Mechanical
  • FRONT BRAKE CALIPER Tektro Aries MD-M280 | Mechanical
  • REAR BRAKE LEVER Tektro JL-510
  • FRONT BRAKE LEVER Tektro JL-510
  • ROTORS Stainless | 160mm

Drivetrain

  • REAR DERAILLEUR Shimano TZ-500 | 6s
  • REAR SHIFTER Shimano TX-30 | 6s
  • CRANKSET Alloy | 28T Narrow Wide
  • CASSETTE Shimano | 6s | 14-28T
  • CHAIN KMC Z | 6s

Wheels

  • FRONT RIM V2 Comp db | 21mm inner
  • FRONT HUB Formula Disc | QR 9x100mm
  • REAR RIM V2 Comp db | 21mm inner
  • REAR HUB Formula Disc | QR 10x135mm
  • SPOKES Stainless 14G
  • TIRES Kenda Amrak | 20x2.20

Accessories

  • PEDALS Wellgo M113

Weight

11.38 kg / 25.09 lb
*For a size medium complete bike, weight approximate and subject to change.
Bike Specifications are subject to change without notice. Specifications may not be exactly as shown in photo.

Frame &
Geometry

*THE PERFECT FIT Please note that only Devinci authorized retailers are able to advise you properly on the correct bike size. Please visit your nearest store so they can analyze your needs. In the case of internet shopping, it is equally important to provide the necessary measurements (e.g. inseam length) so that the retailer can give you the correct information.

A - ST (MM)
B - SA (DEG)
C - HA (DEG)
D - TT (MM)
E - REACH (MM)
F - CS (MM)
G - WB (MM)
H - BBH (MM)
I - SOH (MM)
J - STACK (MM)
K - HT (MM)
RIDER HEIGHT (CM)

Full range

3 bikes

Selected bike

Ewoc 20'' 6S

Unavailable

  • Suntour XCT 80mm Fork
  • Kenda Amrak 20x2.2 Tires
  • Shimano TZ-500 Rear derailleur
Compare + Added! Delete

Devinci owners manual

Download Devinci's user manual

Warranty

View our warranty policy
