E-Troy GX 12S LTD Made in Canada
US$7,999.00
Select your specs
-
Aluminum
Frame
-
GX 12S LTD
Build kit
E-ALL MOUNTAIN
See what happens when maximum output meets legendary all-mountain capability with the new E-Troy. Everything about the E-Troy was designed with power in mind. The suspension kinematics, dedicated mixed wheel configuration and true MTB geometry create a riding experience that feels immediately familiar and startlingly potent. Don’t settle for e-bikes that let a motor drag you around the trails. Take control of your ride and go further than ever with the made-in-Canada E-Troy.
Technical
Specifications
E-Troy GX 12S LTD
Manufacturing
Handcrafted in Canada
Frame
- FRAME Aluminum Optimum G04 150mm
- HEADSET FSA Orbit | 1.5 | Zero Stack
- SEAT CLAMP Alloy CNC | 34.9mm
Suspension
- SUSPENSION FORK Fox 38 Performance Elite Grip2 170 | 51 Offset
- REAR SHOCK Fox Float X Performance Elite Evol LV | 0.4VSpacer| 185x55T
Cockpit
- HANDLEBAR V2 Pro E | B:35mm | R:15mm | W:780mm
- STEM V2 Pro E | B:35mm | L:40mm | 0°
- SADDLE SDG BELAIR Max eMTB
- SEATPOST SDG Tellis 31.6mm
- SEATPOST LEVER SDG Tellis | Matchmaker | 1x Lever
- GRIPS Devinci Performance | w/lock-on
Brakes
- FRONT BRAKE SRAM Code R | 4 Pistons
- REAR BRAKE SRAM Code R | 4 Pistons
- ROTORS SRAM Centerline | 200mm
Drivetrain
- REAR DERAILLEUR SRAM GX Eagle | 12s
- REAR SHIFTER SRAM GX Eagle 12s Single Click
- CRANKARM FSA CK-762 Bosch
- CHAINRING Sram X-Sync Eagle 34T EMTB
- CASSETTE SRAM PG1230 | 12s | 11-50T | HG
- CHAIN SRAM GX Eagle | 12s
- CHAIN GUIDE GN4 Mini Guide
Wheels
- FRONT TIRE Maxxis Minion DHF | 29x2.5WT | 3C | Exo+ | TR | MaxxTerra
- REAR TIRE Maxxis Minion DHR II 27.5x2.4" 3C Compound, TR, DD
- FRONT WHEEL RaceFace Aeffect R30 29 Boost110x15 | 30mm inner
- REAR WHEEL RaceFace Aeffect R30 27.5 B148x12 HG | 30mm inner EMTB
E-System
- COMPUTER BOSCH System controller BRC3100
- DRIVE UNIT BOSCH Performance Line CX | 85Nm
- BATTERY BOSCH PowerTube | 625Wh
Weight
24.65 kg / 54.34 lb
*For a size medium complete bike, weight approximate and subject to change.
Bike Specifications are subject to change without notice. Specifications may not be exactly as shown in photo.
Full range
7 bikes
FAQ ABOUT THE E-TROY
What is the difference between the GX 12s model and the GX 12s LTD?
The LTD features 170mm of fork travel and is equiped with the Bosch Smart System and the System Controller display and comes with Bosch's A4 Charger. The GX 12s has 160mm of fork travel and is equiped with Bosch's Kiox System 2 display and comes with Bosch's Standard Charger.
What is the battery autonomy?
It is important to mention that there is a lot of factors on which will depend the autonomy of the battery. The average speed, the mode you're using the most, the weather, the wind, the rider's weight, and the stop frequency, all these factors play a role in the mileage you can put in one charge.
With an average speed of 15km/h, in summer weather, in mountainous terrain, using the ECO mode, one charge will give you approximately 94 KM of autonomy.
Can I instal a range extender?
Yes, the E-Troy Bosch is compatible with Bosch's PowerMore 250. An additional bottle-sized battery that is compact and weighing 1.6kg.
How much does it weigh?
From 24.65 kg / 54.34 lb
Is it UDH™ compatible?
Yes, the E-Troy Bosch is compatible with Universal Derailleur Hanger and therefore, also compatible with Sram's Transmission.
What are the benefits of a mixed-wheel configuration?
Get all the snappy handling of a 27.5" wheel in the rear with the added traction, rollover and momentum of a 29" wheel up front.
Can I remove the battery?
The dropdown style battery is easy to remove and is kept secure with a key lock.
What is the estimated recharge time?
With the A4 Charger, it will deliver 50% charge in approximately 2.1 hours. A full charge will approximately take 5.4 hours.
With the Standard Charger, it will deliver 50% charge in approximately 2.1 hours. A full charge will approximately take 5.4 hours.
What is the warranty on the E-Troy Bosch?
The frame is covered with a lifetime warranty. Components are covered with their manufacturer's warranty policies.
Is the Bosch Smart System offered on all E-Troy Bosch models?
No, only on the E-Troy Bosch GX 12s LTD
What are the benefits of the Bosch Smart System?
It lets you customize and decide with which support and dynamics as well as with which maximum torque and up to which maximum speed the e-Bike will take you forward. You can adapt all riding modes to your needs in the Bosch eBike Flow app.
Where can I find more information regarding Bosch's products?
Can I route the cables externally?
No, the cables are routed internally.
What is the tire clearance for the rear wheel?
27,5'' x 2.6''
Can I instal a rear shock with a longer stroke to gain more travel?
No, the E-Troy Bosch was designed with a Trunnion 185 x 55mm shock. Fitting a shock with a different size will void your warranty.
What travel fork can I use on this bike?
Either 160mm or 170mm.
Can I install a 29'' rear wheel to make it full 29'' ?
No, the rear end of the E-Troy was specificaly designed for a 27,5'' rear wheel. A 29'' rear wheel simply won't fit.
Technologies
MADE IN CANADA ALUMINUM FRAME
Made from 6061-T6 aluminum tubes for superior durability, incredible stiffness and a knockout strength-to-weight ratio exclusive to Devinci bikes.
DEDICATED MIXED-WHEEL SIZE DESIGN
Get all the snappy handling of 27.5" with the added traction, rollover and momentum of a 29" wheel up front.
27.5 X 2.6 MAXIMUM TIRE CLEARANCE
27.5 x 2.6
LIFETIME WARRANTY
The love of riding lasts a lifetime. Now your bike can too.
INTERNAL CABLE ROUTING
BOSCH MOTOR
The Performance Line CX motor is one of the most advanced e-bike motors on the market. It combines a powerful dynamic drive system with efficient power management. You get the most from your motor for the whole ride, every ride.
STANDARD BOOST 148
Boost 148 design with a 55 mm chainline that offers ample tire clearance.
REMOTE POWER SWITCH
The thumb-actuated Mini Remote lets you adjust power settings without changing your hand position. The remote is connected to the system controller via Bluetooth, making it easy to mount it where you want.
NEW 625WH BATTERY
A long-lasting and powerful 625Wh battery uses 18650 cell technology. Its rugged design is purpose-built for the rigours of mountain biking.
DROPOUT SPEED SENSOR
Clean, streamlined solution to clunky, outdated spoke magnets, with internalized cable routing.
CHAINGUIDE-EQUIPPED
Ultra-tough, lightweight chainguide for headache-free chain-holding security.
FRAME PROTECTION
Integrated high-density chain stay protectors deliver a silent ride and peace of mind while the nylon motor/battery protector keeps out rocks and debris.
31.6 SEAT POST
S → 125 | M → 150 | L → 170 | XL → 200
Insertion length:
S → 225 mm
M → 250 mm
L → 275 mm
XL → 300 mm
UPDATED GEOMETRY
Modern trail bike geometry featuring a slacker head angle for confidently tackling technical sections, while the steeper seat tube angle helps you tackle the climbs.
REMOVABLE BATTERY
The dropdown style battery is easy to remove and is kept secure with a key lock.
ENDURO™ BEARINGS
Enduro™ double-lip sealed bearings for precision movement and superior longevity.
UNIVERSAL DERAILLEUR HANGER
Reduces the risk of destroying your derailleur and makes it easy to source replacement parts when you need them.
4A SUPERCHARGER
High-output charger delivers 80% charge in roughly 2 hours.
E-MTB OPTIMIZED SPLIT PIVOT
Separates acceleration forces from braking forces for a buttery smooth ride complemented by hyperactive small-bump compliance. Additionally, optimized kinematics keeps the e-bike suspension active, even when accelerating, for added torque and improved overall traction.
RANGE EXTENDER
Portable energy reserve : PowerMore 250 is the additional drinks-bottle-sized battery for even more range and longer-lasting trail fun. Compact and weighing only 1.6kg, this range extender can be easily stowed in your backpack until you need it. If you don't need it, your water bottle can fit in its holder. For rides with lower energy requirements, you can leave your main battery at home and rely fully on PowerMore 250.
BOSCH - eMTB MODE
The eMTB mode provides targeted support for eMountain biking and always delivers power exactly when it's needed. Whether on steep sections or individual obstacles. This is precisely when it delivers up to 340% of the rider's own power and a maximum torque of 85 Nm.
BOSCH ASSISTANCE MODES
Optimized ride: Bosch's riding modes are precisely adapted for every riding situation. Eco, Tour, Sport, Turbo.
